| Spare Parts |   |
| 896H-1CH-D1SW-R1-12VDC | | ORIGINAL MANUFACTURER PART NUMBER |
| Specification | Type: Changeover Relay
Colour: Black
Weight: 42 g
Contact Form: 1C (SPDT)
Rated Current: 150 mA
Max. Continuous Voltage: 133 %
Power Consumption of Rated Voltage: 1.8 W
Contact Rated Voltage Drop: 50 mV at 10 A
Coil Voltage: 12 VDC
Coil Protection: Resistor
Coil Resistance 80 Ohms
Contact Material Silver Tin Oxide
Normally Open 50A 14VDC
Normally Closed 30A, 14 VDC
Series 896H
Enclosure Style Dust cover with weather proof and steel bracket
| | Type | Changeover Relay | |
Colour | Black | |
Weight | 42 g | |
Contact Form | 1C (SPDT) | |
Rated Current | 150 mA | |
Max. Continuous Voltage | 133 % | |
Power Consumption of Rated Voltage | 1.8 W | |
Contact Rated Voltage Drop | 50 mV at 10 A | |
Coil Voltage | 12 VDC | |
Coil Protection | Resistor |
|
| |
|
