| Spare Parts |   |
| 871-1C-C-R1 24VDC | | ORIGINAL MANUFACTURER PART NUMBER |
| Specification | Type: Changeover
Colour: Black
Weight: 20 g
Contact Form: 1C (SPDT)
Rated Current: 59 mA
Max. Continuous Voltage: 133 %
Power Consumption of Rated Voltage: 1.4 W
Contact Rated Voltage Drop: 40 mV at 10 A
Temperature Range: -40 °C to +125 °C
Coil Voltage: 24 VDC
Coil Protection: Resistor
Contact Material Silver Tin Oxide
Enclosure Style Flux Tight
Normally Open 35A 14VDC
Normally Closed 20A 14VDC
Coil Resistance 410 Ohms
Series 871
| | Type | Changeover | |
Colour | Black | |
Weight | 20 g | |
Contact Form | 1C (SPDT) | |
Rated Current | 59 mA | |
Max. Continuous Voltage | 133 % | |
Power Consumption of Rated Voltage | 1.4 W | |
Contact Rated Voltage Drop | 40 mV at 10 A | |
Temperature Range | -40 °C to +125 °C | |
Coil Voltage | 24 VDC | |
Coil Protection | Resistor |
|
| |
|
